TEXA A/C Forming Gas Leak Detector S0755H

TEXA Forming Gas Leak Detector
Accurately detect micro leaks in R134a, R1234yf, and R744 (CO₂) A/C systems using forming gas (95% nitrogen / 5% hydrogen).

• Detects hydrogen levels from 0–2,000 ppm (1 ppm sensitivity)

• Fast response time (~14 seconds)

• 8" flexible probe for hard-to-reach areas

• Visual & audible leak indicators

• Lightweight & portable (up to 6 hours on 2 AA batteries)
  Eco-friendly and more precise than traditional dye methods. Daimler AG-compliant.

H2 DETECT
– H2 measurement spectrum: from 0 to 2000 ppm
– Response threshold: the hydrogen concentration is measured in
increases of 1 ppm
– Reaction time: 14 s
– The measuring sensor is positioned at the end of a flexible
extension that is 200 mm in length.
– The tool also provides a visual and acoustic feedback about the
hydrogen concentration
– Power supply: 2 x 1.5 V Mignon /AA
– Battery life: approx. 6 h (typical)
– Operating conditions: from -10 to 40 °C /from 14 to 104 °F
– Weight: approx. 200 g (battery included)
– EC directives: 94/9/EC (ATEX), 2014/30/EU

****For use with S0755K leak detection kit
